GTX 3000-H4 (10KWh)

SKU: GTX-3000-H4-10KWh Categories: ,

Technical Specification

MODEL GTX 3000-H4
Parameters
Battery pack quantity 4
System nominal voltage (V) 204.8V
System nominal energy (100%DOD) 10kWh
System available energy (90% DOD) 9kWh
Dimension (W*D*H) 515*480*770
Weight 160
Protection class IP65
Cooling Natural
Battery module parameters
Nominal Voltage 51.2Vdc
Nominal Capacity 50AH
DOD < 90%
Nominal Charging Current 25A
Max. Continuous Charging Current 30A
Nominal Discharging Current 25A
Max. Continuous Discharging Current 30A
Working Temperature -20 ℃~ 60℃
Storage Temperature ≤ 25℃, 12 months
≤ 35℃, 6 months
≤ 45℃, 3 months
Environmental Humidity ≤ 95%RH (No condensation)
Max. Operating Altitude ≤ 2000m
Certificates UN38.3, IEC62619, IEC62040-1, SAA etc
Cycle Life 6000 [email protected] 80% DOD / 25℃ / 0.5C, 60% EOL
